Snugger’s SS4200 is primarily used to pre-heat engines allowing for easy starts in cold weather climate. It can also provide a level of comfort heat when plumbed through an onboard heater exchanger. The coolant heaters are operated with a simple ON/OFF switch or an optional programmable timer.
When added to the onboard water circuit, cold engine starts are eliminated because the unit will tap directly into your vehicle’s fuel supply and battery system. Snugger offers both an 4 & 5 kilowatt coolant heaters that have the ability of increasing coolant and thus increasing engine block temperature significantly in less than an hour. This allows for an engine start similar to that of a summer’s day.
MODEL SS4200
Heat flow control High Low
Heating output Btu/hr (Kw) 14400 (4.2) 7500 (2.2)
Fuel consumption US gal / hr (L /h) 0.13 (0.51) 0.06 (0.25)
Fuel Diesel
Electric power consumption (watt)/ amp running (12 and 24 Volt) Operating 53 (4.41 /2.20 ) 27 (2.25/ 1.12)
Startup 120 (10/5)
Rated voltage (V) 12 24
Operating voltage range Minimum voltage 10.2 V or 21V
(Low-voltage protection will shutdown the units when it reach to approx. 10.2 volt and 21 volt.)
Maximum voltage 16 V or 32V (Over-voltage protection will shutdown the units when it reach to approx. 16 volt and 32 volt.)
Water capacity of the heater 0.046gal (0.175 L)
Water through-put capacity 225-265 US gal/ hr (approximately operational pressure 10Kpa)
850-1000L/h (approximately operational pressure 10Kpa)
Minimum water through-put capacity 63.5 US gal / hr (240 L/h)
Weight (excluding heating medium and optional etc.) 6.8 lbs approximately 3.1 kg
