| MODEL | KSB06 | KSB07 | KSBO8 | KSBO9 | KSB10 | KSB11 | KSB12A | KSB13 | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Cooling capacity | W | 18600 | 22090 | 25400 | 27900 | 30200 | 32550 | 34880 | 41860 | ||
| Refrigerant | R134A | ||||||||||
| Refrigerant charge | Kg | 4.5 | 5.5 | 7.0 | 7.2 | 7.5 | 7.5 | 10.0 | 12.0 | ||
| Weight | Kg | 165 | 195 | 215 | 235 | 240 | 250 | 260 | 302 | ||
| Total curent | A | 65 | 78 | 79 | 86 | 86 | 96 | 105 | 153 | ||
| Compressor | Model | WX40 | F400 | 4PFCY | 4PFCY | 4NFCY | 4NFCY | 4NFCY | 6PFCY | ||
| Displacement | Cm³ | 400 | 400 | 558 | 558 | 647 | 647 | 647 | 836 | ||
| Lubricant | PAG | BSE55 | BSE55 | BSE55 | BSE55 | BSE55 | BSE55 | BSE55 | |||
| Evaporator | Type | Tube and fin (whorled in tube hydrophilic aluminum foil) | |||||||||
| Air flow rate | M³/h | 3200 | 3900 | 4000 | 4800 | 4800 | 6000 | 6000 | 7800 | ||
| Fan | Double shaft centrifugal type (long service life, low noise, high efficiency) | ||||||||||
| Condensor | Type | Tube and fin | |||||||||
| Air flow rate | M³/h | 5700 | 6600 | 7200 | 8800 | 9600 | 9600 | 11000 | 11400 | ||
| Fan | Axial flow type (long service life, low noise, high efficiency) | ||||||||||
| Dimensions | Length | mm | 3508 | 3395 | 3710 | 4295 | 4295 | 4295 | 4800 | 6000 | |
| Width | mm | 1720 | 1860 | 1860 | 1872 | 1872 | 1872 | 1872 | 1860 | ||
| Height | mm | 175 | 175 | 185 | 175 | 175 | 175 | 175 | 175 | ||
| Control System | Inside temperature | °F (°C) | Condition from 64.4°F (18°C) ~ 82.4°F (28°C) | ||||||||
| Defrost temperature | °F (°C) | 33.8°F (1°C) ~ 37.4°F (3°C) | |||||||||
| Air flow | 3 step air flow | ||||||||||
| Safety device | High pressure switch | Mpa | Action pressure 2.65 mpa reset pressure 1.65 mpa | ||||||||
| Low pressure switch | Mpa | Action pressure 0.04 mpa reset pressure 0.14 mpa | |||||||||
| MODEL | KSY04 KSY04B | KSY05 | KSY06 | KSY07A | KSY07 | |||
|---|---|---|---|---|---|---|---|---|
| Cooling capacity | W | 12000 | 16000 | 18600 | 19000 | 22090 | ||
| Refrigerant | R134A | |||||||
| Refrigerant charge | Kg | 3.0 | 4.0 | 4.5 | 4.5 | 4.5 | ||
| Weight | Kg | 80 / 100 | 120 | 130 | 125 | 140 | ||
| Total curent | A | 52 | 67 | 67 | 72 | 67 | ||
| Compressor | Model | WX26 | AK33 | F400 | GDC-320 | 4TFCY | ||
| Displacement | Cm³ | 260 | 330 | 400 | 320 | 475 | ||
| Lubricant | PAG | PAG | BSE55 | PAG56 | BSE55 | |||
| Evaporator | Type | Tube and fin (whorled in tube hydrophilic aluminum foil) | ||||||
| Air flow rate | M³/h | 2600 | 3200 | 3200 | 4000 | 3200 | ||
| Fan | Double shaft centrifugal type (long service life, low noise, high efficiency) | |||||||
| Condensor | Type | Concurrent flow condenser | ||||||
| Air flow rate | M³/h | 4400 | 6600 | 7600 | 7600 | 8000 | ||
| Fan | Axial flow type (long service life, low noise, high efficiency) | |||||||
| Dimensions | Length | mm | 2323 / 1980 | 2675 | 2828 | 2560 | 2828 | |
| Width | mm | 1204 / 1600 | 1690 | 1690 | 1577 | 1830 | ||
| Height | mm | 210 / 190 | 197 | 197 | 195 | 197 | ||
| Control System | Inside temperature | °F (°C) | Condition from 64.4°F (18°C) ~ 82.4°F (28°C) | |||||
| Defrost temperature | °F (°C) | 33.8°F (1°C) ~ 37.4°F (3°C) | ||||||
| Air flow | 3 step air flow | |||||||
| Safety device | High pressure switch | Mpa | Action pressure 2.65 mpa reset pressure 1.65 mpa | |||||
| Low pressure switch | Mpa | Action pressure 0.04 mpa reset pressure 0.14 mpa | ||||||
